| The TL3-A Intrinsically SafeReference Thermometer for Field and Laboratory |
| The Intrinsically Safe TL3-A thermometer is the latest evolution
of ThermoProbe’s industry standard TL series. The TL3-A has
been certified to the latest global standards for hazardous
locations (Ex). |
| A large display and easy to hold design makes the TL3-A more
convenient for use as a reference in the lab or field. The rugged
plastic alloy case and buttons are well suited for use in industrial
applications, even with gloves. The TL3-A innovative circuitry
provides improved temperature accuracy, response time and
battery life. |
| TL3-A thermometers are intended to be used anywhere a
precision glass stem thermometer or other type thermometer is
used |
| Versatile software functions allow easy selection of Celsius or
Fahrenheit units and display resolution. Minimum, maximum
and average temperatures are automatically stored to memory
for later reference. Low battery display, and failure mode
indications protect the user from false data. Encoded Calibration
is unaffected by temperature, vibration, or battery removal. |
| Through numerous distributors equipped for calibration and
repair, the TL3-A can be supported in many locations
throughout the world |
| A one year warranty, protective case and NIST traceable
4 point calibration report are included |
| Temperature |
Accuracy- +/-0.1°F (0.06°C)
-standard calibration 14°F to 320°F
Standard- 4 point calibration: 32°F(0°C) , 120°F(49°C),
199°F(93°C) & 300°F(149°C)
Resolution: 0.01 Degrees
Range: -40°F to 400°F (-40°C to 204°C)
-Note: Standard calibration does not provide
full range accuracy
Custom calibration points and ranges available.
Temperature time constant:-
6 seconds in circulated water bath
(time response to 63.2% of temp. step change)
Recommended minimum immersion depth: 3" (7.6cm)
|
| Interface Features: |
0.5" (12.7mm) character LCD
Switchable units °C or °F
Resolution 0.1 or 0.01
Low Battery & Fault indication
Continuous operation or Auto Off after 20 minutes.
Stores and displays Average, Lowest & Highest readings.
Arrows indicating increasing/decreasing temperature.
Recommended ambient temperature range: 32°F to 112°F
(0°C to 44°C) |
| Construction: |
Stainless steel RTD temperature sensor
- 100Ω Shock resistant Thin-Film RTD
- Standard 8"(20cm) or 12"(30cm) lengths
- Standard 0.25"(6.35mm) diameter
with 0.188" (4.76mm) reduced tip
Static-dissipative plastic enclosure with a durable
polyester graphics window.
Nominal body dimensions: 5 x 1.75 x 0.85"
(13 x 4.4 x 2.2cm)
Nominal weight: 4 oz (113 grams) |
 |
| Battery: |
3V Duracell DL2032 coin cell
Over 150 hours service life at 70°F (21°C)
Ambient temperature operating range -4°F to 140°F
(-20°C to 60°C)
Note: Battery may not provide adequate power if used
outside operating range |
|
|
Portable: |
✓ |
NIST Traceable: |
✓ |
Certified Intrinsically Safe (Zone 0): |
✓ |
Extended Battery Life: |
- |
Weather Resistant: |
- |
Bluetooth: |
- |
Display Resolution: |
0.01 |
Tolerance: |
0.1°F (0.06°C) |
Uncertainty: |
0.03°F (0.017°C) |
Hazardous Location Marking: |
ATEX & IECEx (Ex ia IIC T4) |
Battery service life (Hours): |
150 |
Temperature Range: |
-40°F to 400°F (-40°C to 204°C) |
Calibrated Temperature Range: |
14°F to 320°F (-10°C to 160°C) |
Calibration (See Note): |
4 Points Standard:
32°F (0°C), 120°F (48.9°C),
200°F (93.3°C), 300°F (148.9°C) |
Batteries: |
CR2032 Coincell
Lithium Manganese |
Ambient Range of Operation: |
-4° to 104° F (-20° to 40° C) |
Temperature Respons |
6 seconds in water bath |
Sensor: |
1/4" diameter Stainless steel sensor
tube
with 3/16" reduced tip, 100 Ohm Class
A RTD |
Enclosure construction: |
Static Dissipatative Plastic - EX rated |
Weight (with 8" sensor) |
4 oz (113 g) |
Operational Features |
Auto off or continuous operation,
Min, Max and Average readings,
Display in C or F |
|
|
| Distillations, temperature baths, melting point tests, flash point tests, reference, thermowells, provers, temperature calibration for flow meters. |
Industries: |
Laboratory
Petroleum
Pipeline
Pharmaceutical
Food |
|
|
|
|
|
|
|
